Rigwire

Hardened Gas Detector and Chromatograph System
By iBall Instruments LLC

Oxygen, CO2, Methane, Ethane, Propane, Butane, H2S, And More

Combined triple redundant Infrared and hot wire system

FOR TECHNICAL SUPPORT PLEASE CALL 405-570-4449

Learn About The Rigwire System

Learn about the Rigwire system by reading our online documentation, or download software, tools, brochures, manuals, and data sheets to help you gain as much information as possible about the Rigwire Gas Detector and Chromatograph System.

LEARN ABOUT THE RIGWIRE EQUIPMENT LEARN ABOUT THE LEGACY BLOODHOUND EQUIPMENT LEARN ABOUT OUR ACCESSORIES

Log Into The Rigwire Platform

When you are a customer and have been given access rights to the system, you will be able to log into the Rigwire Platform and interact with your equipment and systems. Watch interactive charts, real time data, update, calibrate, maintain your system remotely, and send text messages to all connected employees and users.

LOG INTO THE RIGWIRE PLATFORM

Become A New Customer

By becoming a new customer of iBall Instruments you can begin to make your life easer and better with new innovative equipment and services.

BECOME A NEW CUSTOMER

RIGWIRE® INFORMATION

The Rigwire Equipment

More powerful, useful, and flexible than the Bloodhound, The Rigwire is made from 6061 billet aluminum. The Rigwire Gas Detector and Chromatograph system is a new clean sheet design of an industry requirement and need for an easily utilized, solid, robust, small, compact, environmentally hardened, accurate and reliable compact system to monitor gasses, the drilling, operation, production and safety in the field, plant, or distribution of all your natural resources.
The creation and implementation of this new type of instrument is the culmination of the last 25 years brought together in a small lightweight usable platform intended to replace older and less reliable field equipment.

The Rigwire is designed for, but not limited to, two primary roles.
(1) The first is to directly and actively plug-and-play replace the current problematic Pason® Gas Detector systems found on hundreds of active wells all over the world.
(2) The second is to replace older, inaccurate, and antiquated gas detection equipment in the field for monitoring, mud logging, management, and safety.

A Few Rigwire System Features

• Redundant thermal coefficient detectors
• Redundant pellistor (hot wire) detectors
• Infrared hydrocarbon and carbon dioxide detectors
• Lead based industrial oxygen reaction sensor
• Medical grade 20,000 hour pumps
• Four minute chromatograph
• Easy serviceable parts
• Automated or manual standard calibration injection port using standard calibration gasses
• 100% Pason compatible for replacement of Pason field equipment gas detectors
• Explosion proof case and design for the harshest of environments
• RSA 2048 bit government level encrypted communications
• Wireless communications
• Optional cellular connectivity

Rigwire Data Sheet

Learn about the Rigwire System through a simple two page data sheet that goes over the system in a brief and concise way.

Download Now

Rigwire Equipment Manual

The Rigwire Equipment Manual provides in-depth system information and descriptions of the functionality, design, interface, limits, and operation of the Rigwire equipment. It is all you will ever need to learn how to interface your equipment with Rigwire.

Download Now

Rigwire Software Manual

The Rigwire Software Manual is a document that is detailed on how the Rigwire Interface software interacts with the hardware as well as all of it's functions and uses for the user.

Download Now

Rigwire Software

The Rigwire Software is an interactive software platform that allows the user to interface to the Rigwire system as painlessly and easy as possible.

VERSION 2 -- For Windows 10 and 11. Digitally Signed

Download Now

LEGACY BLOODHOUND® INFORMATION

Legacy Bloodhound Equipment

NOTICE: The Bloodhound gas detection and Chromatograph logging system is now integrated into the Rigwire Platform.

The Bloodhound gas detection and logging system is based on patented next generation infrared sensors that are light years ahead of the older hotwire, FID or Pelister based gas sensors. No other mud logging gas detection system uses this technology that makes it possible to create a system without peer in sensitivity, precision chromatography, reliability, portability, ruggedness, accuracy, and ease of use.

The Bloodhound® can interface with WITS equipped drilling rigs to log all other drilling operations data along with collected gas sample data. Both WITS and sample gas data can be encrypted and sent through the internet to our secure servers via ethernet or the on board 4G cellular card. Authorized users can log into our secure Multiview web site and view the status of dozens of drilling operations in near real time, or view more detailed information and gas charts on any selected drill site with just a few mouse clicks. The system can be configured to send a text message if something goes wrong like a clogged gas sample line or loss of power. In addition to identifying the hydrocarbons coming in from the sample line, the Bloodhound® can also identify and measure Oxygen, Carbon Dioxide, and Hydrogen Sulfide.

A Few Bloodhound System Features

• 0-100% auto ranging
• Total gas & Chromatograph C1 – iC5 & nC5
• Sensitive and Linear without Saturation
• No filament, flame or pelistor to fail
• No saturation
• No in field calibration (set and stable for 18 months)
• No drift from filament degradation
• No drift from carbonization
• CO2 -included
• H2S -included
•Triple redundant data records
• Real time (6 second new data capture cycle)
• Data viewing at rig site or anywhere worldwide via website
• WITS compatible
• Automatically generated real time mud log
• Automatic sample flow monitor and Adjustments
• Hardwire and wireless communication capabilities
• Built in GPRS data modem eliminates satellite dish and rental costs
• Alarm notification via cell phone text message worldwide
• Remote diagnostics on sample flow, sample line vacuum pressure, total hydrocarbons and other functions
• Multiple function automatic alarms based on custom high/low parameters
• Automatic alarm notification via cell text
• message24/7 remote manned alarm monitoring service packages

Bloodhound Real Time Data Viewer

Some users of the web site data viewing also like to watch the real time numbers come in over the internet. This small program displays data that is 6 seconds old and gives real meaning to the term “Real Time.” The program is written in VB6 and is backward compatible to Microsoft Windows and tested on all Microsoft windows products.

Download Now

WITS Simulator System

This WITS simulator is an easy way to test your WITS system directly from your computer. This software will talk to your Bloodhound through an available computer serial port. Just connect a null modem cable from any available serial port on your computer and the Bloodhound serial WITS connector, select the serial port that it is connected to, and hit the start button.

Download Now

Bloodhound Data Sheet

Learn about the Legacy Bloodhound System through a simple two page data sheet that goes over the system in a brief and concise way.

Download Now

Bloodhound Equipment Manual

The Bloodhoud Equipment Manual provides in-depth information and descriptions of the functionality, design, interface, limits, and operation of the Bloodhound System. It's all you will ever need to learn how to interface your equipment with it.

Download Now

Bloodhound Gas Chart Software Manual

The Bloodhound Software Manual provides details on how the Bloodhound Interface software interacts with the hardware and defines all functions and uses for the user.

Download Now

Bloodhound Gas Chart Software

The Bloodhound Software is an interactive software platform that allows the user to interface to the Bloodhound system as painlessly and easy as possible.

For Windows 10 and 11. Digitally Signed

Download Now

ACCESSORIES INFORMATION

Cavitator Gas Extractor Data Sheet

A quick overview of the Cavitator system.
The Cavitator BY FAR is the best priced, best performing, lightest, safest, most reliable and easiest to set up gas extraction system on the market today. Improvements to the Cavitator system are being made constantly as customer feedback allows us to perfect this extremely versatile gas extraction system.

Download Now

Cavitator Gas Extractor Equipment Manual

Typically, the mud gas extractors employed today are an overly heavy construction, potentially unsafe, and are very hard to manipulate or adjust.
The iBall Instruments Cavitator brand of mud gas extractor allows for the easy manipulation of adjustments, ease of service, and safety for the users and area.
Using a common and easily adjustable 3 part platform that is attached to the drilling spoil separator (also known as the Shaker, Possum Belly), the user can choose between 4 various types of powered Cavitation motors.
The 3 part attachment platform is comprised of the Clamp assembly, Arm assembly, and Barrel assembly. We feel you will be much happier at how easy this product will make your life.

Download Now

Bubble Jar Fluid Catch

This new patent pending liquid collecting and blocking device will help eliminate the ability for liquids to be pulled into your sensitive analytical equipment and causing thousands of dollars in damage!
This new liquid collection device has a floating check valve built directly into the lid that will block the travel of liquids to your sensitive equipment and will not let them pass!
As this container fills to the limit, the floating valve blocks any other liquids from being pulled into your highly sensitive equipment which can cause thousands of dollars in repairs and days of down time while it is being repaired!
If one of these liquid containers is activated and is blocking liquid due to liquids moving towards your equipment, just clear out the water from within the housing and you are still going strong.
Without the iBall instruments catch jar you may be down hours or days until a replacement instrument can be had or the damaged one repaired.

Download Now

H2S Company Policy And Our Equipment

iBall Instruments is exceptionally confident in the Bloodhound system gas detection system that it promotes, rents, and sells. This policy is in regards to the Hydrogen Sulfide detector manufactured by e2v that the Bloodhound uses. The sensors we use have proven to be highly stable, reliable, and functional over a long periods of time. In all cases, if the Bloodhound detects the presence of Hydrogen Sulfide, it is to be treated as true Hydrogen Sulfide gas extracted directly from the sample drilling fluid.

Download Now

CO2 Company Policy And Our Equipment

iBall Instruments is exceptionally confident in the Bloodhound system gas detection system that it promotes, rents, and sells. This policy is in regards to the Infrared Carbon Dioxide detector that the Bloodhound uses. The sensors we use have been proven to be highly stable, reliable, and functional over long periods of time. Specifically for more than two years of constant use.

Download Now

iBall Instruments LLC
3210 S. Arena Rd., McLoud Oklahoma 74851
For Office or Sales Please Call 405-341-2434

FOR TECHNICAL SUPPORT PLEASE CALL 405-570-4449
